Bulletproof (Laminated)Glass is a high-grade safety glass, composed of multiple layers of glass and film.
The total thickness of the bulletproof glass is directly proportional to the bulletproof effect. The film thickness in the bulletproof glass structure is related to the bulletproof effect.
According to the different thicknesses of glass and laminated film, it can effectively resist pistols, Tommy guns, rifles, and other different gun shooting.
Feature
|
Composition |
Tempered glass+PVB/SGP/EVA film+ tempered glass |
|
Thickness |
Glass Thickness: Triple: 5+5+5mm, 6+6+6mm, 8+8+8mm, 10+10+10mm, and other custom thicknesses or multilayers, with different thickness interlayers. Interlayer Thickness: 0.38mm and multiple of 0.38mm PVB/EVA, 0.76mm and multiple of 0.76 mm SGP (Dupond Sentry Glass Plus) |
|
Size |
Produce custom size as per customer's demand, Max size could reach to 3300x13000mm |
|
Glass Color |
Custom, clear, ultra clear, grey, green, blue, bronze |
|
PVB/EVA color |
Red, white, yellow, any pantone color |
|
Shape |
Flat / Curved, customized |
|
Glass Type |
Annealed or toughened laminated glass in Clear, Tinted, Reflective, Low Iron, Etched, Mirrored, Textured, Colorsmart,Thermocolour, screen printing, and Low E combinations |
|
Processing |
Cut to size, custom shape, polish edges, drill holes, cutouts, cut notches, etching, printing, sandblasting, safety corners, etc. |
|
Quality Standard |
Meet ISO, CCC, SGCC ANSI Z97.1-2015, CE EN12150 EN12600 EN14449:2005, BS6206 etc. standard |
APPLICATIONS
-
Sloped security glazing & skylights
-
Places where safety is required like balustrade
-
Security areas subjected to ballistic attacks
-
Sound control & privacy areas
-
Cash teller/jewelry shop protection, etc.
